You are now directed to the 'API connection configuration' drawer. Here, you configure an MSP API connector entering all necessary details.

Connector Name - Give a suitable title to the connector
Authentication & Grant Type - We have set up default values for these fields as OAuth V2 and Authorization Code with PKCE. These fields are uneditable by users.

Upon registering your Grid application in Microsoft Azure Active Directory (Azure AD which is now Microsoft Entra ID), you can obtain the details for the following 3 fields below (which are specific to your account):

Client ID
Client Secret
Azure AD/Microsoft Entra Tenant ID
SharePoint URL - Enter your Sharepoint account URL where the data is stored for MS Project.

After having entered all the details, click on the 'Authorize' button.

Now, you need to allow Grid access your Microsoft account for Microsoft Project. You will do this by signing into your MS account. Once it is done, you get a message in green saying, ‘Your Authorization was successful’.

Click on ‘Next’.
